8045-II High Accuracy Digital Multi-meter resolution 10V Big lcd display(RUOSHUI 8045-II)
Product details
| Management number | 213672811 | Release Date | 2026/04/12 | List Price | $47.26 | Model Number | 213672811 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
VC8045-II Bench-Type Digital Multi-meter 4 2/1 high performance Bench-type DMM, Liquid crystal display. It can be used to measure AC and DC voltage, current, resistance, diode, continuity, frequency, capacitance, triode and other parameters, and has data hold, Max. or Mi. Value, backlight relative value and other functions. The max. voltage measuring can up to 1000V DC or AC peak value. Resolution can be 100mV, and current measuring can up to 20A, it also has the function of polarity auto-change, backlight displaying and directly reading. For AC measuring, it is performed by high accuracy TRUE RMS, can test the bandwidth of the frequency, and the TRUE RMS of any waveform can be accurately measured. Special Function Diode test √ Frequenc √ Resistance √ Triode test √ Continuity buzz er √ Overload protection √ ACV frequency response 50kHz Operation way Manual range Max. Display 19999 Dimension 260mm*220mm*82mm Weight Approx:1Kg Power AC220V/110V 47Hz-62Hz
- This instrument digital Multi-meter is a high performance of 4½ digital bench Multi-meter
- TRUE RMS,measuring DCV, ACV, DCA, ACA, OHM, CAP, Hz, hFE, Diodes and Continuity
- Manual range ⑶ 4 1/2-digit large LCD display with backlight
- Frequency, resistance, capacitance, triode, diode test and continuity test. Overload protection:250V rms
- Has the function of polarity auto-change, backlight display and directly reading.
| Color | Orange |
|---|---|
| Model | EO-RUOSHUI 8045-II |
| Brand Name | RuoShui |
| Style Name | Clamp Meter/Multimeter |
| Unit Count | 1.0 Count |
| Item Weight | 1 Kilograms |
| Manufacturer | Xi'an Beicheng Electronics Co.Ltd(RUOSHUI) |
| Power Source | Battery Powered |
| Item Dimensions | 7.87 x 5.91 x 7.09 inches |
| Specification Met | CE, RoHS, UL |
| Included Components | RUOSHUI 8045-II |
| Upper Temperature Rating | 60 Degrees Celsius |
| EU Spare Part Availability Duration | 1 Years |
